The WCVR71-SHB Covert Shoulder Bag Camera System is a self-contained, low-profile video recording and WiFi monitoring platform built into a casual black shoulder bag / waist pack form factor. Designed for authorized undercover operations, confidential informant deployments, controlled meetings, field interviews, mobile surveillance, and static placement, the WCVR71-SHB provides a practical everyday-carry concealment with professional covert video capability.
The system features an HD1080 pinhole camera, onboard microSD recording, and ConnectX WiFi transmission for remote monitoring and camera management. All operational components are discreetly located in the front left pocket beneath the flap, giving the operator easy access to the battery and microSD card slot without disturbing the appearance of the bag.
For fast deployment, the battery connection serves as the primary power on/off control. Connect the supplied lithium battery to power the system on, and disconnect the battery to power the system down. The microSD card slot uses a standard push-type design for straightforward card installation and retrieval.
The WCVR71-SHB is well suited for agencies that require a familiar, casual concealment that can be quickly issued, worn, placed, recovered, and redeployed. The adjustable strap allows the bag to be worn crossbody, over the shoulder, around the waist, or positioned for static use depending on the operational requirement.
The shoulder bag remains functional for carrying small personal items, helping preserve its ordinary appearance during use while keeping the camera system accessible for setup, battery replacement, and media retrieval.
The WCVR71-SHB uses the MAXSUR ConnectX platform to support local recording and wireless management. Operators can configure recording settings, view live video, manage microSD card settings, and use supported remote monitoring workflows through the ConnectX setup process.
For setup, WiFi configuration, SD card formatting, live view, recording options, and remote monitoring, refer to the MAXSUR ConnectX Module Operation Guide. For battery charging and lithium battery safety guidance, refer to the MAXSUR BATT-CHG-LI-S1 Supplement Manual.
| Specification | Detail |
|---|---|
| SKU | WCVR71-SHB |
| Product Name | Covert Shoulder Bag Camera System |
| Concealment Type | Casual shoulder bag / waist pack |
| Camera | HD1080 pinhole camera |
| Recording | Onboard microSD recording |
| Wireless Capability | ConnectX WiFi transmission for remote monitoring and management |
| Storage Type | microSD card |
| Recommended Storage | HD video-rated microSD card, 32GB or larger recommended |
| microSD Access | Standard push-type microSD card slot |
| Power | Rechargeable single-cell lithium battery |
| Power Control | Battery connection functions as system power on/off |
| Battery Connector | JST-style connector |
| Charging Method | Supplied USB single-cell lithium battery charger |
| Charge Complete Indicator | Red charger light turns off when charging is complete |
| Equipment Location | Front left pocket beneath flap |
| Carry Method | Adjustable strap for shoulder, crossbody, waist-style, or static placement use |
| Exterior Color | Black |
| Base Bag Capacity | Approximately 2.5 liters |
| ConnectX Reference | MAXSUR ConnectX Module Operation Guide |
| Battery Charger Reference | MAXSUR BATT-CHG-LI-S1 Supplement Manual |
| Intended Users | Authorized law enforcement, investigative, and security personnel |
